Technical Specification
GRADE | TP304/304L, 304H, TP316/316L, 316Ti, TP317/317L, TP321/321H, TP347/347H, S31260, S31500,S31803, S32550, S32750, S32760. |
---|---|
SIZE: | 1/2â³ TO 36â³ [10MM TO 900 MM] |
SPECIFICATION | ASTM, ASME/ANSI, AFNOR(NFE), DIN, EN, BS, JIS Etc. |
APPLICATIONS | Nuclear Power Plants, Oil & Gas, Petrochemical & Refinery, Chemical & Fertilizer,Power Plant & All major process industries. |
Standards/ Types And Pressure Class:
ASME/ANSI B 16.5 | WELDING NECK FLANGE, SLIPON FLANGE, BLIND FLANGE, HIGH HUB BLIND FLANGE, SOCKET WELD FLANGE, LAP JOINT FLANGE, THREADED FLANGE, RING TYPE JOINT FLANGE |
---|---|
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
ASME/ANSI B 16.47 | WELDING NECK FLANGE, BLIND FLANGE [SERIES A & B] |
PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
ASME/ANSI B 16.36 | WELDING NECK FLANGE, SLIPON FLANGE, THREADED FLANGE |
PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
BS 4504 SEC 3.1 | WELDING NECK FLANGE, HUBBED SLIPON FLANGE, HUBBED THREADED FLANGE, LAPPED PIPE END FLANGE, PLATE FLANGE,LOOSE PLATE FLANGE, LOOSE PLATE WITH WELD NECK FLANGE, BLANK FLANGE |
PRESSURE CLASS | PN 2.5 TO PN 40 |
BS 4504[PART 1] | WELDING NECK FLANGE, HUBBED SLIP-ON HUBBED THREADED, PLATE FLANGE, LOOSE PLATE WITH WELD ON PLATE COLLAR, BLANK FLANGE |
PRESSURE CLASS | PN 2.5 TO PN 400 |
BS 1560 BOSS | WELDING NECK FLANGE, SOCKET WELDING FLANGE, SLIP-ON FLANGE, BLIND FLANGE,SCREWED BOSS FLANGE, LAPPED FLANGE |
PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
BS10 | WELDING NECK FLANGE, PLATE SLIP-ON FLANGE, SCREWED BOSS FLANGE, SLIP-ON BOSS FLANGE, BLIND FLANGE |
TABLE | D, E, F, H |
DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, |
PRESSURE CLASS | PN 6 TO PN 100 |
